acoustic impedance: seismic velocity multiplied by density. A reflection coefficient exists where there is a change in acoustic impedance.

composite reflection: the arithmetic sum of several overlapping reflection events.

composite waveform: the arithmetic sum of all waveforms produced at closely spaced interfaces that occur within the distance spanned by one seismic wavelet.

detected thin bed: a bed that creates a seismic reflection event wherein the top and bottom boundaries of the bed are so close together that they cannot both be positioned at a peak and/or trough in zero-phase data.

dominant wavelength: the distance between two identical phase points on an oscillating function. Typically wavelength is measured between adjacent peaks or troughs, identified by the symbol l.

one-way traveltime: the length of time required for a seismic wave to propagate between two defined points. The direction of travel can be up, down, or lateral.

peak amplitude: the amplitude of the positive portion of a seismic wiggle-trace response.

phase point: a fixed position on a seismic wavelet, such as the extrema of a peak, extrema of a trough, or a zero crossing.

resolved thin bed: a bed where the top and bottom boundaries of the bed are positioned at the apex of a peak and/or trough in a zero-phase seismic response.

resonance peak: an increase in reflection amplitude caused by closely spaced reflection events adding in phase to increase wavelet amplitude.

Ricker wavelet: a particular type of seismic wavelet based on the assumption that attenuation is proportional to the square of the frequency.

seismic thin bed (regime): a seismic bed or regime is regarded as ́thinî when its thickness is less than º of the dominant wavelength of the seismic wavefield that illuminates the bed. The thickness of thin layers is inferred mainly from seismic reflection amplitude measurements, whereas the thickness of thick layers is determined mainly from differences in traveltimes.

seismic wavelet: a seismic pulse usually consisting of one and one-half to two cycles.

trough amplitude: the amplitude of the negative position of a seismic wiggle-trace response.

tuning thickness: the bed thickness at which the amplitude of the reflected waveform is a maximum. (See resonance peak).

two-way traveltime: the length of time required for a seismic wave to propagate between two defined points two times, one path being in the forward direction and the other path in the reverse direction. The forward direction can be down, up, or lateral. Typically, the forward direction is down, and the reverse direction is up.

two-way true thickness: the thickness of a thin-bed layer measured in reflection seismic data, which requires a two-way travel path through the layer that is imaged.

wedge model: a simple model used to illustrate how bed thickness affects seismic reflection character. The reflection coefficients at the bed boundaries may have the same magnitudes but opposite algebraic signs, or equal magnitudes and equal algebraic signs, or both the magnitude and sign of the reflection coefficients can vary.

zero-phase wavelet: a symmetrical seismic wavelet having a right half that is identical to its left half.

zero-phase data: seismic data created by a zero-phase wavelet.
